10 m³
10 m³ horizontal feed mixer and distribution trailers have two horizontally designed augers.
10 m³ horizontal feed mixer and distribution trailers have two horizontally designed augers. The auger system has been developed and developed with the latest technology and experience. With this designed helix system, you can increase the homogeneity to 95%, and at the same time, you can minimize the particle size thanks to the chopper blades made of special design and special materials. 10 m³ feed mixer and distribution trailer can prepare feed for 190 to 200 cattle and 800 to 900 small cattle. Horizontal feed mixer and distribution trailers can be produced in desired sizes and features with tractor, electric and electric / tractor depending on demand.
| POWER SOURCE | TRACTOR |
| LENGTH (A) (mm) | 5700 |
| HEIGHT (B) (mm) | 2500 |
| BANDED WIDTH (D) (mm) | 2450 mm |
| BANDLESS WIDTH (D1) (mm) | 2300 mm |
| WHEEL TRACK WIDTH (D2) (mm) | 2300 mm |
| CURRENT WEIGHT (KG) | 3900 |
| POWER REQUIREMENT (PTO) | 80 hp |
| PTO SPEED | 540 D/dk |
| WHEEL DIMENSIONS | 12,5/80-15,3 |
| NUMBER OF BLADES | 72 |
| SCREW SYSTEM | HORIZONTAL DOUBLE |
| WEIGHING SYSTEM | OPTIONAL |
| FEED DISCHARGE DIRECTION | SINGLE RIGHT |
| TRACTOR SEPARATOR SYSTEM | HYDRAULIC JACK |
| REAR LOADER BUCKET | AVAILABLE |
| TRANSMISSION PTO OUTPUTS | COUPLE |
| BASE SHEET THICKNESS (mm) | 5 |
| SIDE SHEET THICKNESS (mm) | 10 |
| DISCHARGE TAPE | AVAILABLE |
| HYDRAULIC DRAIN COVER | AVAILABLE |
| FULL HYDRAULIC SYSTEM | AVAILABLE |
| DRAWING AND WHEEL SYSTEM | AVAILABLE |
| NUMBER OF ANIMALS | 180 |
